AN ISO 9001 : 2015
Precision and General Engineering Steel tubes are manufactured as cold formed from Hot rolled, Cold rolled and hot rolled pickled steel of various physical and chemical properties
Machine parts, automobiles, bicycles, furniture, transformer, General Mech & Engg purposes, Idlers & Conveyors etc.
Conforming IS-3074,
IS-3601, IS-7138,
IS-9295 & BS-6363
– Outside diameter : From 12.7mm (1/2") to 101.6mm(4") – Wall thickness : 0.6mm to 4.85mm – Length : Up to 8 mtrs.
Mill's certificate or inspection by an independent Agency
Black (Self-coloured),
Outside oil coating
Dimensional Checking, Hydraulic Pressure Test, Flattening Test, Drift test.
Plain
Bare Bundles
| O.D. / MM | WALL THICKNESS / WEIGHT (kg/mtr) | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.60 | 0.80 | 1.00 | 1.25 | 1.60 | 2.00 | 2.50 | 2.90 | 3.25 | 3.65 | 4.05 | 4.50 | 4.85 | 5.00 | 5.50 | 6.35 | 7.00 | |
| 1/2" - 12.70 | .179 | .235 | .289 | .353 | .438 | .527 | |||||||||||
| 5/8" - 15.88 | .226 | .297 | .378 | .465 | .580 | .704 | |||||||||||
| 3/4" - 19.05 | .273 | .360 | .450 | .555 | .695 | .845 | |||||||||||
| 7/8" - 22.23 | .325 | .425 | .530 | .648 | .828 | 1.020 | |||||||||||
| 1" - 25.40 | .371 | .495 | .612 | .753 | .950 | 1.165 | 1.411 | 1.609 | 1.775 | ||||||||
| 1.1/4" - 31.75 | .615 | .765 | .951 | 1.200 | 1.475 | 1.803 | 2.063 | 2.284 | 2.529 | 2.766 | |||||||
| 1.1/2" - 38.10 | .915 | 1.145 | 1.450 | 1.791 | 2.195 | 2.517 | 2.793 | 3.100 | 3.401 | ||||||||
| 2" - 50.8 | 2.230 | 1.527 | 1.940 | 2.405 | 2.978 | 3.425 | 3.811 | 4.244 | 4.669 | ||||||||
| 2.1/2" - 63.50 | 2.442 | 3.033 | 3.760 | 4.338 | 4.829 | 5.387 | 5.937 | ||||||||||
| 3" - 76.10 | 3.654 | 4.537 | 5.234 | 5.838 | 6.521 | 7.196 | 7.945 | ||||||||||
| 3.1/2" - 88.90 | 4.285 | 5.326 | 6.150 | 6.864 | 7.673 | 8.474 | 9.365 | 10.052 | |||||||||
| 4" - 101.60 | 4.912 | 6.109 | 7.058 | 7.882 | 8.816 | 9.742 | 10.775 | 11.571 | |||||||||
| 5" - 127 | 6.165 | 7.675 | 8.875 | 9.917 | 11.103 | 12.280 | 13.594 | 15.043 | 16.479 | 18.893 | 20.714 | ||||||
The above range is only indicative. Demension & Thickness other than specified can also be supplied as required.
O D : ± 0.25mm max
Wall Thickness : + 8% Excluding Weld
